HIMEL PLUG IN RELAY 14PIN 24VAC 5A 4C/O WITH LED HDZ9054LBR
Note: Image for illustrative purpose only, original product will be delivered as per your order specification on the item description, please refer technical data sheet for more information about the product.
COIL VOLTAGE : 24 VAC
CURRENT RATING : 5A
NUMBER OF CHANGEOVER CONTACTS : 4
NUMBER OF PINS : 14 PIN
MOUNTING TYPE : PLUG-IN
PRODUCT WARRANTY : 24 MONTHS
HS Code : 8536 4900
Lead Time : 2-4 WORKING DAYS
VIEW MORE PRODUCT DETAILS
Related Products
Product or component type |
Plug in relay |
Function |
Used to implement the conversion of intermediate control signals and low-power output. In the field of industrial control, used in conjunction with contactors, relays, circuit breakers, etc. |
Standard |
EN60947-1/EN60947-5-1 |
Rated working current |
5-10A |
Coil voltage |
AC6V-380V ,DC6V-220V |
Installation method |
PCB & Socket |
Warranty period |
24 months |
Specifications
| Brand | HIMEL |
| Model Number | HDZ9054LBR |
| COIL VOLTAGE | 24 VAC |
| CURRENT RATING | 5A |
| NUMBER OF CHANGEOVER CONTACTS | 4 |
| NUMBER OF PINS | 14 PIN |
| MOUNTING TYPE | PLUG-IN |
| PRODUCT WARRANTY | 24 MONTHS |
| Lead Time | 2-4 WORKING DAYS |
| Warranty | 2 year warranty |
